dbSpectra DBS-HC113T1-8F 800MHz Control Station Combiner (8ch)

This is a dbSpectra brand 8 Channel Control Station Combiner, model number dbs-hc113t1-8f. Combiner is in great shpe and guaranteed fully operational. This unit is designed to handle 800 Mhz Frequencies in the 806-869 Mhz range. Hutton List price on this combiner is over $8500.00.

Additional Information

• Separate transmit and receive antennas.
• Low profile building block modules.
• Transmit and receive on each radio port.
• Enables combining of control stations.
• 50 Watts input per channel (continuos).
• Enhances system port-to-port isolation.
• Amplifier for receive signals.
• Analog or digital radio compatible

Reduce the number of antennas needed with the dbSpectra Control Station Combiner, a trunked or conventional mobile radio combiner/multicoupler. Connect eight mobile radios with our 8-port model and reduce antenna requirements from eight to two. Your overall system port-to-port isolation can be increased using this combiner for applications where individual radio antennas do not provide enough spatial RF isolation, thus removing all the guesswork

NOTE: If your order includes programming, please email us a request for our Programming Form after checkout. We will only program up to 16 channels and do not program for trunking systems.
